PBFK-260 INDUCTION SEALING MACHINE (WATER-COOLING )

Availability:

Product Description

PBFK-260 INDUCTION SEALING MACHINE (WATER-COOLING )

• Applicable for sealing different -size round, rectangular and most irregular bottles and containers .

• Stainless steel SUS 304 main machine frame and housing .

• Water cooling effect.

• It equips rejection system for missing foil caps .

• It adopts no-contact induction sealing between the bottle and sealing head which make the bottle mouth seal properly .

• One conveyor for bottles transmission with speed variator .

• TOUCH SCREEN CONTROL .

• 4 wheels and 4 anti-vibrator legs.

• Meets GMP requirement .


Water cooling automatic bottle induction sealing machine TECHNICAL DETAILS


Model

PBFK-200

Max.capacity

180 Bottles/Min ( Depends on bottle mouth Dia. )

Size of cap

Diameter : 15-70 MM

Size of Bottle

15-1000 ML

Height of bottle

30-300mm

Voltage

220V   50/60HZ

Power

4KW

Overall Dimension

1600 (L)*950(W)*1250(H)mm

Weight

250kg (with conveyor)
